Liquid Crystal Display Silicone Gel Dehumidifier 12L

Desiccant dehumidifier is in conformity with all provisions of European security requirements&standards, the safety works for people and equipment are done while in design and manufacture process. In each section of the manual, there is safety information, explicitly pointed out that the dangerous operation, "Danger Mark" was marked in the front for warning.

SKU: https://www.alibaba.com/product-detail/Liquid-Crystal-Display-Silicone-Gel-Desiccant_1601387660390.html?spm=a2747.product_manager.0.0.453671d2K2suUr Category:

Share on FacebookTweet about this on TwitterShare on LinkedInShare on Google+Pin on Pinterest
INQUIRY

















Liquid Crystal Display Silicone Gel Desiccant Dehumidifier 12L

Desiccant dehumidifier is in conformity with all provisions of European security requirements&standards, the safety works for people and equipment are done while in design and manufacture process. In each section of the manual, there is safety information, explicitly pointed out that the dangerous operation, “Danger Mark” was marked in the front for warning.

In the manual the best dehumidifier operation ways and procedures are provided, but they do guide only, are not liable for any personal responsibility or fulfill local safety regulations. While installation and operation of the equipment, everyone shall bear the liability:

  • To protect equipmentaccording to the manual describes and explains the security;
  • Do care safety of yourself and others;
  • Dehumidification devices operation and maintenanceworks must be done by related qualificationprofessionals;
  • Do not installdehumidification equipmentaround the explosion protection devices;
  • Cut off power before open any cover in the housing;
  • When the operation ended, cooling equipment at least 15 minutes,then begin maintenance;
  • If not for dehumidify equipment maintenance, the maintenance panel should be closedif the maintenance is not being doing;
  • Dehumidification equipment is limited to atmospheric pressure condition to dehumidifying;
  • Filter devicemust be installed before using the dehumidification equipment, or the desiccant wheel devices will be polluted, thus losing dehumidification ability.
  • Removing or deleting the marks/declares/notes in dehumidification equipmentis prohibited;
  • The manual should be kept well for using in the future;
  • Original spare partsshould be choosen;
  • The written permission from manufacture must be needed before repairing dehumidification equipment;
Model KCDD-8/ Painting KCDD-8/ Stainless KCDD-2 / Painting KCDD-2/ Stainless
Voltage 220-240V~50Hz 220-240V~50Hz 220-240V~50Hz 220-240V~50Hz
Capacity 8L/D(30℃/80%RH) 8L/D(30℃/80%RH) 12L/D(30℃/80%RH) 12L/D(30℃/80%RH)
Rated Power 400W 400W 600W 600W
Wheel Type Silicon Gemstone ф155*20mm Silicon Gemstone ф155*20mm Silicon Gemstone ф155*30mm Silicon Gemstone ф155*30mm
Heating Type PTC 400W PTC 400W PTC 500W PTC 500W
Fan Type Axial Flow Fan Axial Flow Fan Backward-inclined Fan Backward-inclined Fan
Ambient Operating Temperature 0-38℃ 0-38℃ 0-38℃ 0-38℃
Air Volume 100m³/h 100m³/h 180m³/h 180m³/h
Sound ≤50dB(A) ≤50dB(A) ≤52dB(A) ≤52dB(A)
Air Inlet Specifications ODф133mm ODф133mm ODф133mm ODф133mm
Air Outlet Specifications ODф50mm ODф50mm ODф50mm ODф50mm
Control Type Mechanical Mechanical Mechanical Mechanical
Net Weight 4.4kg 4.4kg 5.1kg 5.1kg
Gross Weight 4.7kg 4.7kg 5.4kg 5.4kg
Product Size 340*195*220mm 340*195*220mm 340*195*220mm 340*195*220mm
Packaging Size 365*250*290mm 365*250*290mm 365*250*290mm 365*250*290mm
Loading Quantity 1120/2250/2600 1120/2250/2600 1120/2250/2600 1120/2250/2600
